The scope of application
Applied to the ships with the length 12m or above 12m (<50m) as lamp signal liaison when night navigation.
Products characteristic
- It is convenient to install and replace the bulb, and there are automatic leak holes in the bottom.
- The shell adopts metal material steel, the surface is painted the special mold-powder, has the feature of corrosion-resisting and shock resistant rice.
- The lampshade adopts PC material, it has the feature of ultraviolet radiation resistant nee and does not discolor.
Adopt standard
- Conform to THE INTERNATIONAL REGULATIONS FOR PREVENTING COLLISION AT SEA,1972 and GRADE ENTRY NORMS FOR STEEL SHIPS.
- Conform to GB/T 3028-1995 standard.
Specification
| Name | Type | Visibility | Level arc | Lamp holder | Bulb | Protection class | Cable outside diameter |
Color | Material | Weight |
| starboard light | CXH1-2C | 2n.m | 112.5° |
B15d
|
24V 30W
|
IP55
|
Φ10-Φ12
|
Green | steel | 1.8Kg |
| port light | CXH2-2C | 2n.m | 112.5° | Red | steel | 1.8Kg | ||||
| masthead light | CXH3-2C | 5n.m | 225° | transparent | steel | 1.8Kg | ||||
| stern light | CXH4-2C | 2n.m | 135° | transparent /yellow | steel | 1.8Kg | ||||
| all-round light | CXH6-2C | 2n.m | 360° | Red/ Green/ transparent |
steel | 1.8Kg |
